Wacker Concrete Products
TaylorEquipmentSupply.com (631-928-2555
WACKER REBAR TIER the purely mechanical unit has no need for a power supply. The mechanically executed knot is always tighter than a standard knot performed by hand with a pair of pliers. Ideal for tying concrete reinforcing steel. This unit is suitable for horizontal (ceilings & slabs) as well as vertical (wall) applications.
Model: Wacker DF16 / Wacker Neuson DF 16
Features: One hand operation. The unit can be operated in any position with one hand only. It is possible to tie up to 1000 knots per hour. Operating diameter 1.26" (32mm).
Wire Ties, 17gauge, copper-coated; 77 per strip. 770 per box. 10 boxes per carton. 180 boxes per pallet.
Model | Length | Weight | Price | Shop Here |
25.8" / 34.7" | 4.9 lb. | $ 949.99 | ||
DF 16-kit* | - | - | $ 1,249.99 | no longer avaialble |
Wire Tie Carton** | - | - | $ 375.00 | call to order |
*Model# DF16-kit: Includes: Tool and Carton ( 7,700x) of copper-coated Wire Ties @ $ 1,249.99
**Wacker Neuson 0209325; Wire Tie Carton: 10 boxes ( 770x per box) @ $ 375.00
Wire Tie Pallet: 180 boxes ( 770x per box) copper-coated wire ties (138,600 total), call for pricing.
REBAR CUTTERS offer efficient and easy cutting for reinforced steel bars. The cost per cut is lower when using electric-hydraulic equipment than it is when using alternative cutting techiques.
Models: Wacker RCE-16, Wacker RCE-20, and Wacker RCE-25.
Also available: Wacker RCP-12, Wacker RCP-16, Wacker RCP-20, Wacker RCP-25, Wacker RCP-32.
Features: Electric-Hydraulic machine offers fast cutting of rebar providing efficient results and quiet operation. The unique design makes them ideal for jobsites where portability are necessary.
Includes: Metal Carry Case.
Model | Capacity | Motor | Weight | Price | Shop Here |
5/8" | 120volt / 9.2amp | 15.7 lb. | $ 1,269.99 | ||
3/4" | 120volt / 9.2amp | 22.0 lb. | $ 1,349.99 | call | |
1" | 120volt / 9.2amp | 30.4 lb. | $ 1,779.99 | call |
All Units: 5 second maximum cutting speeed, grade 75 capacity.
CONCRETE VIBRATORS, FLEX-SHAFT on-site vibration of concrete for foundations, walls, columns, and slab work. In plant vibration of concrete during production of pipes, slabs, beams, columns, and walls.
MODELS: Wacker M1000, Wacker M2000, Wacker M3000, & Wacker A5000
FEATURES: Lightweight and rugged. Double insulated and grounded motor. Dual air filters. Motor airflow from rear to front prevents dust buildup. Standard quick disconnect coupling on motor facilitates shaft exchange. Quick release brush covers. Dust and waterproof on-off switch.
Integrated quick disconnect couplings on shafts easily connect to all Wacker motors, offering 62 combinations. Please call for assistance when selecting motor, head, and shaft combinations. Based on your application needs, we will recommend a package to provide optimum performance.
| Power Source | ||
| Model# | Motor / Engine | Weight |
| M 1000 | 1.3 hp electric, 115volt, 9amp | 12 lb |
| M 2000 | 2.3 hp electric, 115volt, 15amp | 13 lb |
| M 3000 | 3.1 hp electric, 115volt, 20amp | 18 lb |
| A 5000 | 5.5 hp Honda, gasoline | 77 lb |
New! Wacker Concrete Vibrator Kits with unique hybrid head to create the best results in concrete consolidation. *Hybrid head (round at the top & square at the bottom). *Increased amplitude. *The innovative design transmits high compaction energy into the concrete providing the best consolidation performance and concrete movement.
Vibrator Kits | Includes Motor, Shaft & Head | |||||
Item# | Motor | Shaft | Head | Weight | Price | Shop Here |
0620354 | M1000 | 6.6' | 1-3/8" x 15.9" | 19.6 lb | $ 729.99 |
|
0620355 | M2000 | 6.6' | 1-3/8" x 15.9" | 28.4 lb | $ 899.99 |
|
0009405 | M2000 | 9.8' | 1-3/8" x 15.9" | 32.2 lb | $ 969.99 |
|
0620356 | M2000 | 13.1' | 1-3/8" x 15.9 | 36.1 lb | $ 999.99 |
|
0620357 | M2000 | 6.6' | 1-3/4" x 15.4" | 30.8 lb | $ 919.99 |
|
0620358 | M2000 | 9.8' | 1-3/4" x 15.4" | 34.6 lb | $ 979.99 |
|
0620359 | M2000 | 13.1' | 1-3/4" x 15.4" | 38.5 lb | $ 1029.99 |
|
0620360 | M3000 | 6.6' | 2" x 15.6" | 36.8 lb | $ 1,069.99 |
|
0620361 | M3000 | 9.8' | 2" x 15.6" | 40.6 lb | $ 1,129.99 |
|
0620362 | M3000 | 13.1' | 2" x 15.6" | 44.5 lb | $ 1,179.99 |
|
0620363* | M3000 | 9.8' | 2-1/2" x 15.2" | 49.8 lb | $ 1,199.99 |
|
Note: Vibrator Kits feature "hybrid" square head, except as noted * features round head.
Accessories: Carrying Strap
| Shafts | ||||||
| Model# | SM1-E | SM2-E | SM4-E | SM0-S | SM1-S | SM2-S |
| Length | 3' | 6.5' | 13' | 1.5' | 3' | 6.5' |
| Weight | 3 lb | 5 lb | 10 lb | 5 lb | 7 lb | 11 lb |
| Model# | SM3-S | SM4-S | SM5-S | SM7-S | SM9-S | |
| Length | 10' | 13' | 16.5' | 23' | 30' | |
| Weight | 15 lb | 19 lb | 23 lb | 31 lb | 39 lb |
Round Heads provide 10,000 vibrations per minute.
| Round Heads | |||||
| Model# | Diameter | Length | Compaction | Capacity | Weight |
| H25S | 1" | 11.7" | 14" diameter | 4 cu yd / hour | 1.8 lb |
| H35S | 1-3/8" | 12.2" | 24" diameter | 12 cu yd / hour | 3.5 lb |
| H45S | 1-3/4" | 12" | 28" diameter | 15.8 cu yd / hour | 5.6 lb |
| H65 | 2-1/2" | 15.3" | 48" diameter | 39 cu yd / hour | 13.4 lb |
Rubber Heads provide 10,000 vibrations per minute.
| Rubber Heads | |||||
| Model # | Diameter | Length | Compaction | Capacity | Weight |
| HR48 | 1-7/8" | 14" | 22" diameter | 18 cu yd / hour | 6.0 lb |
| HR65 | 2-1/2" | 15" | 28" diameter | 22 cu yd / hour | 8.5 lb |
| HR70 | 2-3/4" | 15" | 36" diameter | 35 cu yd / hour | 11 lb |
| HR70S | 2-3/4" | 16" | 30" diameter | 15 cu yd / hour | 6.0 lb |
| Hybrid Heads | ||||
| Model # | Diameter | Length | Vibrations/Minute | Weight |
| H25HA | 1" | 15.9" | 12,000 | 4.4 lb |
| H35HA | 1-3/8" | 16.9" | 12,000 | 5.0 lb |
| H45HA | 1-3/4" | 15.4" | 12,000 | 7.5 lb |
| H50HA | 2" | 15.6" | 12,000 | 8.6 lb |
HIGH FREQUENCY VIBRATORS high frequency motor-in-head internal vibrators with an integrated, compact electronic inverter in the switch housing. Designed for high quality results in foundations, walls, columns, and in-plant production.
MODELS: Wacker IRFU30, Wacker IRFU38, Wacker IRFU45, Wacker IRFU57, & Wacker IRFU65
FEATURES: Lightweight, compact unit plugs directly into standard 115volt outlet. Soft start eliminates amperage surge at start-up. Built-in motor protection for short circuits, ground fault, high temperature, voltage variations, and phase failures. Induction hardened vibrator housing inside and outside for extended operating life. Three phase induction motor. Oil lubricated high performance roller bearings. Fast vibrator head replacement eliminates special tools. Sealed switch housing.
All units: Cable length 50', Vibrations per minute 12,000 , Input voltage 115v.
| Model# | Motor | Head Size | Compaction | Hose Length | Weight | Price |
| IRFU 30 | 4.4amp | 1.2" x 13.9" | 15" diameter | 5 meter / 16.4' | 25.3 lb | $ 1,329.99 |
| IRFU 38 | 7.0amp | 1.5" x 13.6" | 19" diameter | 5 meter / 16.4' | 31.1 lb | $ 1,379.99 |
| IRFU 45 | 9.6amp | 1.8" x 15.0" | 23" diameter | 5 meter / 16.4' | 34.0 lb | $ 1,399.99 |
| IRFU 57 | 12amp | 2.3" x 15.8" | 33" diameter | 5 meter / 16.4' | 43.7 lb. | $ 1,579.99 |
| IRFU 65 | 15amp | 2.6" x 16.7" | 39" diameter | 5 meter / 16.4'' | 56.2 lb. | $ 1,899.99 |
Please call to order High Frequency Vibrators: 631-928-2555
HIGH FREQUENCY VIBRATORS with operating handle and integrated inverter combine performance with ease of operation. The motor-in-head vibrators achieve optimum consolidation performance thanks to their constant high frequency speed and their powerful motor. The 1-meter hose make these vibrators ideal for surface consolidations.
MODELS: Wacker IRSEFU30, Wacker IRSEFU38,Wacker IRSEFU45, and Wacker IRSEFU57.
FEATURES: The ergonomically shaped low vib handle reduces the hand-arm vibrations and makes sure that the operator feels comfortable despite the high centrifugal forces generated by the vibrator. Direct connection to any single-phase power source by way of the frequency inverter integrated in the power cable for a variety of applications. Maintenance-free, long-life motor featuring coil windings with excess temperature class-H protection. The vibrator body and the inverter are absolutely waterproof.
All units: Input Voltage 115volt, Cable Length 49.2', Vibrations per minute 12,000
| Model# | Motor | Head | Compaction | Hose Length | Weight | Price |
| IRSEFU 30 | 4.4amp | 1.2" x 13.9" | 15" | 1 meter / 39" | 24.7 lb. | $ 1,539.99 |
| IRSEFU 38 | 7.0amp | 1.5" x 13.6" | 19" | 1 meter / 39" | 26.5 lb. | $ 1,559.99 |
| IRSEFU 45 | 9.6amp | 1.8" x 15.0" | 23" | 1 meter / 39" | 28.7 lb. | $ 1,749.99 |
| IRSEFU 57 | 12amp | 2.3" x 15.8" | 33" | 1 meter / 39" | 35.3 lb. | $ 1,889.99 |
Please call to order High Frequency Vibrators: 631-928-2555
TROWEL, WALK-BEHIND EDGING specifically designed for up to the edge finishing, this compact trowel eliminates hand work along walls. Offering better floating and finishing capabilities along wall lines and obstacles, Wacker's edging trowel delivers an unmatched solution to the concrete job site.
MODEL: Wacker CT24-4A
FEATURES: Dynamically balanced trowels offer nearly effortless operation. Low vibration handle reduces operator fatigue and increased production. Standard foldable handle makes storage convenient while the standard lifting eye eases transport. Honda GX-series gasoline engine.
Standard Package includes: set of four 9" x 4-3/4" finish blades, 24" float pan, and lift hook.
| Model# | Engine | Diameter | Speed Range | Clutch | Weight | Price | Shop Here |
4.0 hp | 24" | 90-141 rpm | centrifugal | 160 lb | $ 2,129.99 |
|
TROWELS, WALK-BEHIND high production, easily operated power trowels perform accurate and highly productive floating and finishing of large concrete surfaces.
MODELS: Wacker CT36-5A, Wacker CT36-8A, Wacker CT36-8A-V, Wacker CT48-8A, Wacker CT48-11A, and Wacker CT48-13A-V
FEATURES: Dynamically balanced trowels offer nearly effortless operation. "Gyro-Tech" system and gearbox brake stops handle within 270-degrees, protecting operator from runaway handle situation. Trowels feature a 30-degree pitch for better concrete burnishing. Guard ring features tubular framing for easy cleaning. Handle type can be selected to meet individual preferences or jobsite conditions.
STANDARD MODELS: optimum weight distribution reduces the lateral force from the trowel for reduced operator fatigue.
HIGH HORSEPOWER MODELS: provide better torque for low-speed floating and additional weight for those operators who prefer a heavier trowel.
VARIABLE TRANSMISSION MODELS: provides wide speed range for low-speed floating through high-speed burnishing, all in one machine.
All models: 4-blade spiders, Pitch range 0-30 degree, Honda GX-series gasoline engines, and include set of combination blades.
Model# | Engine | Diameter | Speed Range | Clutch | Weight | Price* | Shop Here |
5.5 hp | 36" | 60-125 rpm | centrifugal | 183 lb | $ 2,149.99 | ||
8.0 hp | 36" | 60-125 rpm | centrifugal | 208 lb | $ 2,349.99 | ||
8.0 hp | 36" | 20-200 rpm | variable | 208 lb | $ 2,899.99 | ||
8.0 hp | 48" | 60-125 rpm | centrifugal | 234 lb | $ 2,549.99 | ||
11.0 hp | 48" | 60-125 rpm | centrifugal | 250 lb | $ 2,799.99 | ||
13.0 hp | 48" | 20-200 rpm | variable | 268 lb | $ 3,449.99 |
*Note: price includes Trowel Model and Twist Pitch Handle #0159659, please call for pricing of handle options.
Pro Shift Handle, pitch control, offers infinitely variable transitions for smooth operation.
Low Vibration Handle, enhances operator comfort with reduced hand arm vibration.
Handle Options | |
| Part # | Description |
| 0159659 | Twist Pitch |
| 0164535 | Twist Pitch, Adjustable Height |
| 0159660 | Twist Pitch, Folding |
| 0164617 | Twist Pitch, Adjustable Height, Folding |
| 0159662 | Pro Shift, Adjustable Height |
| 0159661 | Pro Shift, Adjustable Height, Folding |
Accessories: Float Blades, Finish Blades, Lifting Bracket, and Weight Kit.
TROWELS, RIDE-ON easy to operate ride-on power trowels for accurate and highly productive floating and finishing of large concrete surfaces and super flat floors.
MODELS: Wacker CRT36-24A, Wacker CRT36-24A WK, Wacker CRT48-34V, Wacker CRT48-35L, Wacker CRT48-35L-PS
36" FEATURES: Correct power-to-weight ratio and an ergonomically designed twin lever control. Variable clutch. Front and rear lighting system. Factory installed, optional, integrated wheel kit. Air-cooled twin-cylinder Honda gasoline engine.
48" FEATURES: Torsion assist mechanical steering system. Highest blade speeds in it's class. Variable clutch. Front and rear lighting system. Engine choices include a liquid-cooled diesel Lombardini or a liquid-cooled Vangaurd.
| Model# | Engine | Rotor Speed | Blades | Weight |
| CRT 36-24A | 24 hp | 25-165 rpm | 8 | 830 lb |
| CRT 36-24A WK | 24 hp | 25-165 rpm | 8 | 865 lb |
| CRT 48-34V | 34 hp | 25-165 rpm | 10 | 1240 lb |
| CRT 48-34L | 35 hp | 25-165 rpm | 10 | 1340 lb |
Wacker CRT Trowels offers a 2-year gearbox warranty.
All units come standard with Combination Blades.
Accessories: Transport Dolly Wheel Kit, Finish Blades, Combo Blades, Float Blades, and Float Pans.
WET SCREED a high production unit for quick and accurate strike-off of concrete slabs with or without the support of grade stakes and forms for commercial applications.
MODEL: Wacker P35A, replaces Wacker P31A
FEATURES: Variety of blade lengths and widths provide jobsite versatility. Unique twin handle system is fully height and angle adjustable. Squeeze grip handle is foldable for easy transport and storage. Adjustable eccentric weights provide additional versatility. Double set of exciter bearings require no greasing for long life. Lightweight unit features front lifting handle for easy transport.
Power Unit | ||
Model# | Engine | Weight |
1.6 hp Honda, 4-cycle, gasoline | 32 lb |
| Screed Kits | |||||
| Model# | Screed Length | Screed Width | Weight* | Price | Shop Here |
| P35A-4 kit | 4' | 4.9" | 41.6 lb | $ 1,749.99 |
|
| P35A-6 kit | 6' | 4.9" | 45.4 lb | $ 1,819.99 |
|
| P35A-8 kit | 8' | 4.9" | 49.2 lb | $ 1,899.99 |
|
| P35A-10 kit | 10' | 4.9" | 53.0 lb | $ 1,979.99 |
|
| P35A-12 kit | 12' | 4.9" | 56.8 lb | $ 2,029.99 |
|
| P35A-14 kit | 14' | 4.9" | 62.5 lb | $ 2,119.99 |
|
| P35A-16 kit | 16' | 4.9" | 64.4 lb | $ 2,199.99 |
|
*Operating weight includes Power Unit and Screed Blade.
Oztec Concrete Vibrators
GASOLINE POWER UNITS provide ultimate and immediate adaptability on the job. Utilizing rugged and dependable Honda gasoline engines, coupld to our "speed-up" transmission, vibrator heads develop 12,000 vpm and never drop below 10,000 vpm.
MODEL: Oztec BP-50a & Oztec GV-5W
FEATURES: BP-50a is equipped with a totally enclosed rotary throttle allowing the operator to comfortably control the engine while preventing wet concrete from entering and clogging the throttle mechanism.
Model# | Max Head Size, Steel | Max Head Size, Rubber | Engine | Weight |
BP-35 | 1-1/2" | none | 1.75 hp | 15 lb |
BP-50a | 2-1/2" | 2-1/2", 2-3/4"short | 2.5 hp | 25 lb |
GV-5W | 2-1/2" | 2-3/4" | 5.5 hp | 55 lb |
REBAR SHAKERS the most efficient & cost effective way to vibrate all types of concrete in blockwall cells or walls.
MODEL: Oztec HRBS includes 1 urethane insert installed and 1 spare urethane insert.
Note: Rebar Shaker Head will only work with the special Rebar Shaker Shafts listed. Shafts come with Oztec QD coupler to connect to 1.2 electric motor or BP-35 backpack power units.
Call 631-928-2555 for pricing of Oztec Rebar Shaker, complete with power unit.
Model# | Description |
HRBS | Rebar Shaker Head |
FSRBS05 | 5' rebar shaker shaft, use with 1.2OZ power unit |
FSRBS07 | 7' rebar shaker shaft, use with BP-35 power unit |
RSI-XX | Rebar shaker spare insert #4 - #8 |
Multiquip Concrete Products
REBAR BENDER this portable, operator friendly machine bends up to 1" diameter rebar in approximately 5 seconds. Rollers and collars in a variety of diameters are included to bend a full range of bar sizes. A foot switch is included for high-production bending.
MODEL: Multiquip MB25A, replaces Multiquip MB25HD
FEATURES: 115volt motor. Compact design for use on the jobsite or in the shop. Motor runs only during bending operation for lower noise level and energy efficiency. Electro-mechanical design with sealed gear case prevents contamination and requires no maintenance. Four lifting handles for portability. Tool kit and waterproof cover included.
Model# | Capacity | Range | Motor | Weight | Price |
up to 1" | 0-180 degree | 115volt, 15amp | 300 lb | call |
STATIONARY MORTAR MIXER the Multiquip PRO12 uses a powerful hydraulic drive that is perfect to meet the toughest mix designs. A high capacity fuel tank provides all day running.
MODEL: Multiquip PRO12
FEATURES: Forklift pockets. Retractable folding stabilizers. High capacity fuel tank. Fits in pickup truck with 8 foot bed. Discharge height of 24" to 42". Hydraulic drive and hydraulic dump. Honda gasoline GX390 engine electric start with recoil backup.
Model# | Capacity | Engine | Weight | Price |
12 cu-ft, 3-4 bag | 13hp elec start | 1580 lb | call |
TORO MUD BUGGY QD moves concrete, mud, gravel, dirt, and more over tough job sites. Heavy-duty poly tub can haul or dump 16 cu-ft, up to 2,500 lbs of material.
Models: Toro MB1600.
| Model# | Tub | Capacity | Engine | Weight | Price |
| MB-1600 | 16 cu-ft | 2,500 lb | Honda 13hp | 1,440 lb | call |
Features: Easy-to-Clean heavy-duty poly tub with generous dumping clearance. Ride-on platform. Left or Right handed speed control mounting. Foot pedal dump action. Forklift brackets for for convenient machine loading. Foam-filled tires provide reliabilty on the job site.
